Switch Type
- Unmanaged
Switch Ports
- 16
PoE+ Budget
- Up to 110W
PoE Support
- Yes
Power Consumption
- 4.52 W / 11.31 W
LEDs
- Link, speed, activity, and PoE indicators
Dimensions (LxWxH)
- 280 x 120 x 25 mm (11.0 x 4.7 x 1.0 in.)
Weight
- 0.902 kg (1.99 lbs)
Minimum System Requirements
- Connected devices need Ethernet connectivity and Ethernet cables.
Operating Humidity
- 10–90% (non-condensing)
Operating Temperature
- 0–50°C (32–122°F)
Ports
- 16-port switch with 8 PoE+ ports (first 1–8 ports) and dedicated PoE power budget of 80 W
Mounting
- Wall
Quality Of Service
- 802.1p and DSCP
Storage Temperature
- -40–70°C (-40–158°F)
Warranty and Support
- 2 Year Warranty
MAC Address Table Size
- 8,000 entries
Performance
- 0.01488 Mpps for 10M port
- 0.1488 Mpps for 100M port
- 1.488 Mpps for 1000M port
- Full line rate and a forwarding rate of 64B frame at:
Power
- 54 VDC, 1.66 A
Regulatory Compliance
- FCC Class A, CE
Maximum Power Consumption
- 5.18 W / 13.41 W
Fans
- None
Power Consumption
- 4.52 W / 11.31 W
Storage Humidity
- 10–90% (non-condensing)
Power Saving
- Cable-connected detection, sleep mode
Network Standards
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.3af
- IEEE 802.3at (PoE+)
- IEEE 802.3az
- IEEE 802.3u
- IEEE 802.3x
Bandwidth
- 32 Gbps (non-blocking)
2 Monitors
- External
