TRENDnet’s 8-Port GREENnet Gigabit PoE+ Switch, model TPE-TG44g, reduces equipment and installation costs by delivering data and power over existing Ethernet cables. This unmanaged switch offers four Gigabit PoE+ and four Gigabit non-PoE ports. The PoE+ standard supplies up to 30 watts of power per port for devices such as high-power wireless access points, PTZ (Pan Tilt Zoom) Internet cameras, and VoIP telephony systems.
Auto-sensing technology delivers 30 watts to 802.3at PoE+ devices (up to 2 devices), 15 watts to 802.3af PoE devices (up to 4 devices), and only data to non-PoE devices. GREENnet technology reduces energy consumption by up to 75% when the switch is not in use. Boost office efficiency and reduce network congestion with a total switching capacity of 16 Gbps. LED indicators display device status for efficient troubleshooting. This switch comes in a sturdy metal case and quickly adds PoE+, PoE, and non-PoE devices to your network.
- 8-Port GREENnet Gigabit PoE+ Switch
- IEEE 802.3at and IEEE 802.3af Power over Ethernet (PoE) compliant
- Supports PoE Class 2 (7 watts), 3 (15.4 watts), and 4 (30 watts)
- 4 x Gigabit Auto-MDIX PoE/PoE+ RJ-45 ports
- 4 x Gigabit Auto-MDIX RJ-45 ports
- Provides up to 30 watts for PoE+ (2 ports Max)
- Provides up to 15.4 watts for PoE (4 ports Max)
- Automatically detects the PoE class level of a Powered Device
- 16 Gbps switching fabric
- Forwarding Rate: 1000 Mbps/1,488,000pps; 100 Mbps/148,800pps; 10 Mbps/14,880pps
- Status LEDs: System Power, PoE, 1000 Mbps, and Link/Activity
- 1K Mac address entries
- 96Kbyte memory buffer
- Full wire-speed non-blocking reception and transmission
- Store-and-forward switching method
- Back pressure Flow Control for Half-Duplex mode
- IEEE 802.3x Flow Control for Full-Duplex mode
- Power saving technology powers down unused ports and when a connected device is in standby mode
- Jumbo Frame support up to 9K
- Plug and Play
- Sturdy metal case
-
- Hardware
- Standard
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3at Power over Ethernet (PoE+)
- IEEE 802.3af Power over Ethernet (PoE)
- IEEE 802.3X Flow Control
- IEEE 802.3az Energy Efficient Ethernet
- Ports
- 4 x Gigabit Auto-MDIX PoE+ RJ-45 ports4 x Gigabit Auto-MDIX RJ-45 ports
- Data Transfer Rate
- Ethernet: 10/20 Mbps (Half/Full Duplex)
- Fast Ethernet: 100/200 Mbps (Half/Full Duplex)
- Gigabit: 2000 Mbps (Full Duplex)
- Forwarding Rate
- 11.9 maps (based on 64-byte packet size)
- Data RAM Buffer
- 96K bytes
- Address Table
- 1K MAC entries
- Switch Fabric
- 16 Gbps
- Power
- Input: 100-240 V AC 50/60 Hz, 1.5 A
- Output: 56 V DC, 1.16 A External Power Adapter
- Diagnostic LEDs
- Power, PoE, 1000 Mbps, Link/Activity
- Power Consumption
- Min: 4 Watts (standby)
- Max: 65 Watts
- PoE Max: 60 Watts
- (4 x 15 watts PoE devices connected or 2 x 30 watts PoE+ devices connected)
- Temperature
- Operating: 0° ~ 40°C (32° ~ 104°F)
- Storage: -20° ~ 90°C (-4° ~ 194°F)
- Humidity
- Max. 90% (non-condensing)
- Dimensions
- 142 x 95 x 30 mm (5.6 x 3.7 x 1.2 in.)
- Weight
- 380 g (13.4 oz.)
- Certifications
- CE, FCC
- PoE
- Power over Ethernet
- Up to 15.4 watts for PoE
- Up to 30 watts for PoE+
- PoE: pin 1,2 for power+ and pin 3,6 for power- (mode A)
Package Contents
- TPE-TG44g
- Quick Installation Guide
- Power Adapter (56 V DC, 1.16 A)
