Hardware
Network standards:
IEEE802.3、 IEEE802.3u、 IEEE802.3ab、 IEEE802.3z、 IEEE802.3x、 IEEE802.3af/at、 IEEE802.1p、IEEE802.1q、 IEEE802.1w、 IEEE802.1d、 IEEE802.1s
LED Indicator:
1*Link/Act or PoE LED indicator
1*Link/1*Link/Act mode converting LED indicator
1*PoE mode converting LED indicator
1*PoE Max LED indicator
1*Power LED indicator
1*SYS LED indicator
Interfaces:
8*10/100/1000 Base-T Ethernet ports (Data/Power)
1*10/100/1000 Base-T Ethernet ports (Data)
1*1000 Base-X SFP ports (Data)
Transmission media:
Recommended: CAT5/5e UTP or better
Fan quantity:
N/A
Level of protection:
Lightning protection for ports: 6kV
Lightning protection for power: 6kV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode:
Store-and-forward
Switch capacity:
20Gbps
Packet forwarding rate:
14.90Mpps
Buffer:
12Mb
MAC address table:
16K
Jombo frame:
10K
PoE power supply management:
Support
PoE budget:
Single port: AF: 15.4W, AT: 30W
Whole device: 130W
Input voltage:
100-240V AC 50/60Hz
Power consumption:
Full load: ＜160W
Empty load: ＜12W
Dimension:
294.0mmx179.6mmx44.0mm
Mounting:
Desktop mounting: support
Wall mounting: support
Rack mounting: non-support
Energy Efficient:
Support
Environment:
Operating temperature: 0°C – 45℃
Storage temperature: -40°C – 70°C
Operating humidity: (10% – 90%) RH, non-condensing
Storage humidity: (5% – 90%) RH, non-condensing
Certification:
FCC、CE、RoHS
______________________________________________
Software
L3 Features:
VLAN-based routing
IPv4 static routing adding
Static ARP adding/deleting
ARP aging time configuration
PoE power supply management:
Supports port PoE configuration and power supply with priority
Supports PoE over-temperature protection
Supports PoE scheduled management
Supports intelligent management and PoE-powered device detection
(port status, power assignment and PoE-powered device status)
Security features:
ARP receiving limit
Unknown MAC address discard
DoS attack defense
802.1x security authentication
Radius security authentication
VLAN:
IEEE 802.1Q VLAN
VLAN Layer-3 interfaces
Supports three port modes: Access, Trunk and Hybrid
DHCP Server:
DHCP Server
DHCP Relay
DHCP Snooping
Supports Option 82 policy configuration
Port aggregation:
Static aggregation
LACP dynamic aggregation
Spanning tree:
IEEE 802.1d STP (Spanning Tree Protocol)
IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
Supports edge port
Supports BPDU statistics
Multicast:
IGMP Snooping V1/V2/V3
Supports port fast leave
Port Mirroring:
Supports N: 1 port mirroring
Quality of Service:
SP (Strict Priority)
SWRR (Simple Weighted Round Robin)
WRR (Weighted Round Robin)
Supports 802.1p port trust mode
Supports DSCP port trust mode
Supports a maximum of 8-queue service quality mapping
ACL:
Supports MAC ACL and IP ACL
Loading and upgrade:
Supports FTP/TFTP/HTTP upgrade
Supports configuration import and export
Management and maintenance:
Supports Telnet
Supports SNMP V1/V2/V3
Supports WEB management and maintenance
Supports Ping/Tracert/Connection Detection
CPU Monitoring and memory monitoring
Local visualization management
